Bluetooth LE for Harry's Lap Timer (without GPS support)
The following measurements are streamed to Harry's Lap Timer (HLT) over Bluetooth LE with 25Hz:
- Throttle Position
- Wheel Speed Front Right
- Wheel Speed Front Left
- Wheel Speed Rear Right
- Wheel Speed Rear Left
- Steering Rate
- Steering Wheel Angle
- Yaw Rate
The MAF is an estimated value of MAF, based on the CAN data for engine power and torque.
The following measurements are streamed to HLT over Bluetooth LE with 1Hz:
- Engine Temperature
- Oil Temperature
- Fuel level
The following measurements are optionally streamed to HLT over Bluetooth LE with 1Hz (additional D/KBUS2CAN module needed):
- Cat temperature
- Intake Air Temperature (IAT)
- Battery Voltage
If future versions of HLT enables support for other measurements (like oil pressure, brake pressure etc.), they will for sure be supported by airVent Display.
In this version there are no streaming of GPS data to HLT. One have to rely on the phone/tablets own GPS mdule (1Hz) or use another external one.
